Barres de terre à deux rangées

Barres de terre à visser sur des constructions en acier ; écartement des alésages 50 mm.

Raccordements :
– conducteur plat avec perçage : avec vis hexagonale M10, écrous et rondelle Grower
– conducteur plat (-40 mm) sans perçage : avec borne de sectionnement, par ex. réf. 454 100
– conducteur rond : avec borne de jonction KS, par ex. réf. 301 000 / 301 019 ou avec dispositif de serrage, par ex. réf. 390 150

2x 2 raccordements

2 Products

Part No. 472023 ES 2X2 ASB11 STTZN

GTIN 4013364030312, Customs tariff No. (EU): 85369010, Gross weight: 517.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: St/tZn
Section: 240 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 196 x 60 x 4 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X2 ASB11 STTZN
Référence: 472023
ou équivalent

Certificates

Technical data

Matériau	St/tZn
Section	240 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	196 x 60 x 4 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat d'essai.

Product 472023 was added to Notepad.

Go to Notepad

Product 472023 was added to the cart.

Go to Web-Shop

Part No. 472109 ES 2X2 ASB11 V2A

GTIN 4013364074477, Customs tariff No. (EU): 85369010, Gross weight: 604.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: INOX
Section: 300 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 196 x 60 x 5 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X2 ASB11 V2A
Référence: 472109
ou équivalent

Certificates

Technical data

Matériau	INOX
Section	300 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	196 x 60 x 5 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat d'essai.

Product 472109 was added to Notepad.

Go to Notepad

Product 472109 was added to the cart.

Go to Web-Shop

2x 3 raccordements

2 Products

Part No. 472022 ES 2X3 ASB11 STTZN

GTIN 4013364030305, Customs tariff No. (EU): 85369010, Gross weight: 588.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: St/tZn
Section: 240 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 242 x 60 x 4 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X3 ASB11 STTZN
Référence: 472022
ou équivalent

Certificates

Technical data

Matériau	St/tZn
Section	240 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	242 x 60 x 4 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat de test.

Product 472022 was added to Notepad.

Go to Notepad

Product 472022 was added to the cart.

Go to Web-Shop

Part No. 472119 ES 2X3 ASB11 V2A

GTIN 4013364074484, Customs tariff No. (EU): 85369010, Gross weight: 740.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: INOX
Section: 300 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 242 x 60 x 5 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X3 ASB11 V2A
Référence: 472119
ou équivalent

Certificates

Technical data

Matériau	INOX
Section	300 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	242 x 60 x 5 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat de test.

Product 472119 was added to Notepad.

Go to Notepad

Product 472119 was added to the cart.

Go to Web-Shop

2x 4 raccordements

2 Products

Part No. 472024 ES 2X4 ASB11 STTZN

GTIN 4013364034495, Customs tariff No. (EU): 85369010, Gross weight: 677.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: St/tZn
Section: 240 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 293 x 60 x 4 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X4 ASB11 STTZN
Référence: 472024
ou équivalent

Certificates

Technical data

Matériau	St/tZn
Section	240 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	293 x 60 x 4 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat de test.

Product 472024 was added to Notepad.

Go to Notepad

Product 472024 was added to the cart.

Go to Web-Shop

Part No. 472129 ES 2X4 ASB11 V2A

GTIN 4013364074491, Customs tariff No. (EU): 85369010, Gross weight: 841.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: INOX
Section: 300 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 293 x 60 x 5 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X4 ASB11 V2A
Référence: 472129
ou équivalent

Certificates

Technical data

Matériau	INOX
Section	300 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	293 x 60 x 5 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat de test.

Product 472129 was added to Notepad.

Go to Notepad

Product 472129 was added to the cart.

Go to Web-Shop

2x 6 raccordements

2 Products

Part No. 472021 ES 2X6 ASB11 STTZN

GTIN 4013364027879, Customs tariff No. (EU): 85369010, Gross weight: 866.00 g, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: St/tZn
Section: 240 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 393 x 60 x 4 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X6 ASB11 STTZN
Référence: 472021
ou équivalent

Certificates

Technical data

Matériau	St/tZn
Section	240 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	393 x 60 x 4 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat d'essai.

Product 472021 was added to Notepad.

Go to Notepad

Product 472021 was added to the cart.

Go to Web-Shop

Part No. 472139 ES 2X6 ASB11 V2A

GTIN 4013364074507, Customs tariff No. (EU): 85369010, Gross weight: 1.10 kg, PU: 1.00 pièce(s)

Images

Open PDF

Additional information

CAD files

Matériau: INOX
Section: 300 mm2
Alésages de raccordement Ø: 11 mm
Dimensions: 393 x 60 x 5 mm
Fixation: [2x] 12 x 15 mm
Normes: NF EN 62561-1

produit : DEHN
Type: ES 2X6 ASB11 V2A
Référence: 472139
ou équivalent

Certificates

Technical data

Matériau	INOX
Section	300 mm²
Alésages de raccordement Ø	11 mm
Dimensions (l x l x p1)	393 x 60 x 5 mm
Fixation	[2x] 12 x 15 mm
Normes	NF EN 62561-1
*) Pour l'affectation exacte, voir le certificat d'essai.

Product 472139 was added to Notepad.

Go to Notepad

Product 472139 was added to the cart.

Go to Web-Shop
